Suprema Xpass
Discover XPass, an innovative compact access control system that redefines versatility and performance. Powered by Suprema’s distributed IP access control solution, XPass offers easy installation with its Power-over-Ethernet capability, making it suitable for both indoor and outdoor applications.
Description
Features
TCP/IP & Network interfaces
IP enabled distributed access control system by
ethernet (DHCP or static IP) and RS485 interfaces
Power over Ethernet (POE)
communication and power over a simple CAT5 or 6
cable/supplies up to 600mA of 12Vdc to locking
devices
Enterprise-level access control capacity
controls up to 40,000 users, 128 time schedules,
128 access groups and 64 zones
IP65 weatherproof structure
rugged structure for outdoor installation,
operates between -20℃ ~ 50℃
Easier installation & operation
direct lock relay and Wiegand connection/
command card operation (add/delete users)
Sleek & aesthetic design
slim and sleek size for narrow door frames/
multi-color LED & buzzer for indication
System Conguration
Specification
| Feature | Specification |
| CPU | 400MHz DSP |
| Memory | 8MB Flash + 16MB SDRAM |
| RF Card | 13.56MHz Mifare (XPM) <br> 125KHz EM Prox (XPE) <br> 125KHz HID Prox (XPH) |
| User Capacity | 40,000 users |
| Log Capacity | 50,000 log records |
| Communication Interfaces | TCP/IP, RS485 |
| Wiegand Interface | Input or output (switchable) |
| I/O | 2 x TTL inputs <br> 1 x relay <br> 1 x tamper |
| User Interfaces | Multi-color LED |
| IP Rate | IP65 |
| Operating Temperature | -20℃ ~ 50℃ |
| Operating Voltage | 12V DC |
| Size (W x H x D) | 45 x 130 x 27mm |
| Certificates | CE, FCC, KCC, ROHS |
